This panel shows the 300 mb observed fields for geopotential height and temperatures. 300mb charts depict conditions in the upper troposphere (roughly 9000 meters) where most of the weather producing phenomena occur, otherwise known as the jet stream level.
Geopotential height approximates the actual height of a pressure surface above mean sea-level and is represented by the solid white contours. The geopotential height field is given in meters with an interval of 120 meters between height lines. The 300 mb height field encircling the globe consists of a series of troughs and ridges, which are the upper air counterparts of surface cyclones and anticyclones. The distance from trough to trough (or ridge to ridge) is known as a long wave. Embedded within the long waves are short waves, which are smaller disturbances often responsible for triggering surface cyclone development.
Wind vectors provide information about wind direction and wind speed and are drawn here as tiny red arrows. Wind vectors point towards the direction in which the wind is blowing and the longer the wind vector, the stronger the wind. The unit of magnitude for wind speed as depicted by the wind vectors is meters per second.
Temperature is represented by the color filled regions and the associated values are indicated by the color code located in the lower left corner of the forecast panel. Temperatures are given in degrees Celsius with an interval of 5 degrees Celsius between temperature contours, also called isotherms. The colder temperatures typically associated with upper level troughs are due to the southward transport of colder air in the lower troposphere. Conversely, warmer temperatures associated with upper level ridges result from the northward transport of warmer air in the lower troposphere.
